G12V190ZLC1 JDEC Jinan 190 vessel engine


Series 2000V marine diesel engines



ModelRated Power(kw/hp)Rated speed(r/min)Specific fuel consumption(g/kw’h)Specific oil consumption(g/kw’h)Overall dimension L*B*H(mm)Net weight(kg)
Z12V190BC1800/10801500≤209.4≤1.62642*1588*20705300
Z12V190BC2882/12001500≤209.4≤1.62642*1588*20705300
Z12V190BC81000/13601500≤209.4≤1.62642*1588*20705300
Z12V190BC9882/12001500≤209.4≤1.62642*1588*20705300
Z12V190BC10900/12251450≤209.4≤1.62642*1588*20705300
Z12V190BC11882/12001500≤209.4≤1.62642*1588*20705300
G12V190ZLC11000/13601450≤209.4≤1.62642*1588*20705300
G12V190ZLC21000/13601450≤209.4≤1.62642*1588*20705300
Main technical data
No. and arrangement of cylinders:12,60
Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication











Model of generating setModel of diesel enginesModel of generatorRated Power KWRated voltage VRated frequency HZOverall dimension L*B*H(mm)Net weight KG
CCFJ400/1000Z12V190BCD-2TFC5454-6JH42400390504210*1500*226010500
CCFJ630/1500Z12V190BCDTFC5456-4JH42630390504260*1500*226012000
