PLUNGER COUPLE L28-200100 ZICHAI L8250ZL Diesel generator

Zichai L8250 Diesel Engine Spare Parts List

CYLINDER BLOCK

4 SEAL OF CYLINDER LINER L250-01-049 48 6 CYLINDER HEAD SHIM L250-01-045 16 8 O-RING L250-01-063 16 14 SEAL L250-01-039 64

CYLINDER HEAD

28 INTAKE VALVE L250-03-004A 32 29 INTAKE VALVE SEAT L250-H03-002 32 30 EXHAUST VALVE SEAT L250-H03-034 32 31 EXHAUST VALVE L250-03-031A 32 32 VALVE GUIDE L250-03-003 64 34 ROUND WIRE SNAP RING GB895.2-86-18 64 42 DISHED SPRING L250-03-202 64 43 TAPER VALVE SPRING L250-03-206 320 44 STEEL BALL BC II GB308-77 320 56 SEAL L250-03-008 B 16 57 O-RING 450*7.0 GB 3452.1-92 16

CON ROD AND PISTON

62 CONNECTING ROD SCREW L250-06A-006 64 64 LOWER BEARING (CONNECTING ROD BEARING) L250-06A-012 8 66 UPPER BEARING (CONNECTING ROD BEARING) L250-06A-011 8 73 PISTON RING (3RD RING) L250-05-023 8 74 PISTON RING (2ND RING) L250-05-022 8 75 PISTON RING (1ST RING) L250-05-021 8 COMPLEX OIL RING L250-05-200 8

FUEL INJECTION PUMP

108 PLUNGER COUPLE L28-200100 16 109 BUSH L28-200009 16 110 SPRING L23-200006 16 111 O-RING L28-200011 16 112 O-RING GB3452.1 51.5X2.65 G 16 113 O-RING L28-200012 16 114 O-RING GB3452.1 36.5X2.65 G 16

INJECTOR

122 RED COPPER WASHER 24 CB500-75.18 16 123 ADJUSTING SPRING L250-52-007 8 124 RUBBER RING 69*3.55 GB3452.1-82 32 125 INJECTOR NEEDLE VALVE L250-52-101 16 126 INJECTOR NEEDLE VALVE BODY L250-52-102 16 127 RUBBER RING L250-52-015 16 RED COPPER WASHER L250-52-013 16
